Welcome to cudacountry's SOLIDWORKS Rings and Things Tutorials. The tutorials are written for SOLIDWORKS 2020.
All tutorials use metric units except the Belt Buckle.
The following tutorials with the PDF icon are available for viewing. Download the free reader from Adobe.
Any questions contact us at
![]() |
Table of Contents |
||
Block | ![]() |
![]() |
1. Heart sketch/block. Uses Style Spline tool. Save heart sketch as a block. |
Block | ![]() |
![]() |
2. Star sketch/block. Uses Polygon tool. Save star sketch as a block. |
Part | ![]() |
![]() |
3. Ring Band with Hearts. Heart block. |
Part | ![]() |
![]() |
4. Ring with Cudacountry Text. Text and Star block. |
Block | ![]() |
![]() |
5. Skull and Cross Bones Sketch/Block. Skull and bones are sketched in 3 sketches and combined in one sketch using Convert Entities. Then, made into Block. |
Part | ![]() |
![]() |
6. Ring Aye Matey. Use Surfaces to create "setting" for Chapter 5's Skull and Cross Bones block. |
Part | ![]() |
![]() |
7. Dog Tag. Click here for the army green camo PNG file used as appearance. |
Part | ![]() |
![]() |
8. Bracelet with Hearts. |
Part | ![]() |
![]() |
9. Whistle. Units metric. |
Part | ![]() |
![]() |
10 Ring Container. Click here for decal files. |
Part | ![]() |
![]() |
11. Tube Squeezer. |
Part | ![]() |
![]() |
12. Shark Badge. |
Part | ![]() |
![]() |
13. Container with Threads. Create threads using Thread Feature with Indent. |
Part | ![]() |
![]() |
14. Container with Hexagon Fill Pattern. |
Part | Coming soon |
15. Shark Bag Clip. | |
Part |
![]() |
![]() |
16. Mastercam Belt Buckle or SOLIDWORKS Belt buckle. Units are inches. |
CNC Mastercam for SW |
Coming soon |
17. Use Mastercam for SOLIDWORKS toolpaths Dynamic Area Mill, 2D Rest Mill and Contour to cut out buckle. Also Circle Mill toolpath to cut holes for holding fixture and to mount clips to attach buckle to belt. Create top cut WCS to offset origin and bottom cut WCS for bottom cut holes. | |
![]() |
---|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Sketch heart using Style Spline and save as block. |
![]() |
![]() |
